Παγωμένο μοτίβο επικαλυμμένο με χάλυβα κυματοειδές χρωματισμένο φύλλο στέγης που έχει παραμορφωθεί

In the field of building enclosure and industrial protection, the weather resistance and decorativeness of materials directly affect the quality of the project. As the world's leading provider of color-coated steel solutions, Yintu Steel has launched a new generation of Galvalume (aluminum-zinc) frosted color-coated coils. Through the perfect combination of 55% aluminum-zinc alloy coating and German embossing technology, it provides a full life cycle protection solution for fences, sandwich walls and other scenes that combines corrosion resistance, wear resistance and aesthetics.

1. Core advantages of Galvalume matte color-coated coils

For outdoor high-corrosion environments and architectural aesthetics, our products have five core competitive advantages:

Super strong anti-corrosion system

55% aluminum-zinc alloy coating (ASTM A792), salt spray test over 3000 hours, corrosion resistance is 3 times that of galvanizing

25μm polyester (PE) / fluorocarbon (PVDF) topcoat, UV absorption rate > 99%

Intelligent surface treatment

German servo embossing technology, forming 0.05-0.1mm three-dimensional matte texture

Anti-slip coefficient μ≥0.70, anti-fouling ability increased by 200%

Precise mechanical properties

Yield strength 245-550MPa (corresponding to DX51D-DX57D)

Elongation ≥12%, suitable for complex modeling processing

Environmentally friendly production process

Chromium-free passivation + water-based paint, passed ISO 14001 and SGS green certification

Pre-coating process reduces on-site pollution and improves construction efficiency 60%

Long-term color management

Color fastness of Japanese Kansai paint is level 7 (ISO 105-B02)

15-year color retention commitment (normal environment)

II. Three major technological breakthroughs of Yintu Steel Industry

Nano-ceramic reinforcement technology

Adding ZrO₂ nanoparticles to the coating increases the hardness to 4H and the wear resistance is improved by 80%

Gradient functional coating

Sandwich structure of epoxy resin primer + intermediate transition layer + frosted topcoat, adhesion level 0

Intelligent embossing system

Servo embossing machine equipped with CCD visual detection to achieve ±0.01mm texture accuracy control

III. Typical application scenarios

1. Building enclosure system

Industrial fence: acid-resistant fence of chemical plant, isolation fence of logistics park

Commercial sandwich wall: shopping center exterior wall, hotel modular wall

Public facilities: airport sound insulation wall, subway station enclosure structure

2. Industrial equipment protection

Port machinery protective cover, mining equipment shell

Agricultural greenhouse enclosure, livestock farm ventilation panel

3. High-end decoration field

Villa courtyard fence, resort landscape wall

Art installation surface, commercial space partition

IV. Full-process service system

Customized solution

Thickness 0.4-1.2mm, width 600-1250mm full specifications optional

Support RAL color card 210 colors + frosted depth customization

Quality assurance

Each roll of product comes with: coating composition test report + salt spray test report + coating thickness report

Passed ISO 9001, ISO 14001, SGS triple certification

Technical support

Free BIM modeling support and enclosure structure optimization solution
